Exclusive SHANGHAI SBM PF1214 Blow Bar Introduction
What is PF1214 Impact Crusher?
The PF1214 Impact Crusher is widely used for primary, secondary, and fine crushing of various stones and rocks with a compressive strength of less than 350 MPa, such as granite, marble, and limestone. It is advantageous in industries like roads, railways, reservoirs, electricity power, and building materials for sand and rock production. The leading manufacturers are Shanghai SBM and Henan Limining.
Saikuang Casting: SHANGHAI SBM PF1214 Blow Bar
As the core component of the crushing process, the SHANGHAI SBM PF1214 Blow Bar is engineered for performance and durability. These are thick slabs of metal, typically manufactured from high-chromium alloys, specifically designed to break down abrasive materials like asphalt, concrete, and limestone.
The material selection for the SHANGHAI SBM PF1214 Blow Bar is critical. It is made from advanced chrome mixtures chosen for their exceptional hardness and wear resistance, ensuring a long service life even under the most demanding conditions. When installed on the rotor, the SHANGHAI SBM PF1214 Blow Bar rotates at tremendous speeds, delivering the repeated, violent impacts necessary for effective size reduction.
To maintain optimal crusher performance, using high-quality, precisely matched replacement parts is essential. The SHANGHAI SBM PF1214 Blow Bar, along with other wear parts like impact plates and liners, can be sourced from specialized suppliers like SAIKUANG Casting. These replacement components are manufactured under strict quality control systems, guaranteeing 100% adherence to the original dimensions and performance standards of the genuine SHANGHAI SBM PF1214 Blow Bar, ensuring seamless integration and reliable operation.
SHANGHAI SBM PF1214 Impact Crusher Parts List
| PF1214 Impact Crusher Parts List |
| Series |
Part Number |
Name |
Material |
PCS |
Notices |
| 1 |
PF1214-04-09 |
wear plate |
Custom alloy |
|
|
| 2 |
PF1214-04-10 |
wear plate |
Custom alloy |
|
|
| 3 |
PF1214-04-11 |
wear plate |
Custom alloy |
|
|
| 4 |
PF1214-04-12 |
wear plate |
Custom alloy |
|
|
| 5 |
PF1214-04-13 |
wear plate |
Custom alloy |
|
|
| 6 |
PF1214-04-16 |
wear plate |
Custom alloy |
|
|
| 7 |
PF1214-08-12 |
lock |
Custom alloy |
|
|
| 8 |
PF1214-04-19 |
square steel |
Custom alloy |
|
|
| 9 |
PF1214-08-14 |
protect plate |
Custom alloy |
|
|
| 10 |
PF1214-02-02 |
impact plate |
Custom alloy |
|
|
| 11 |
PF1214-08-13 |
blow bar |
Custom alloy |
|
|
| 12 |
PF1214-01-04 |
tapered flange |
Custom alloy |
|
|
| 13 |
PF1214-08-10 |
big pulley |
Custom alloy |
|
|
| 14 |
PF1214-10-01 |
motor pulley |
Custom alloy |
|
|
| 15 |
PF1214-08-04 |
Inner bearing cover |
Custom alloy |
|
|
| 16 |
PF1214-08-01 |
Outer bearing cover |
Custom alloy |
|
|
| 17 |
PF1214-08-03 |
Bearing sleeve |
Custom alloy |
|
|
| 18 |
PF1214-08-05 |
Axle box labyrinth cover |
Custom alloy |
|
|
| 19 |
PF1214-08-06 |
Outer rotor cover |
Custom alloy |
|
|
| 20 |
PF1214-08-09 |
Outer bearing vent cover |
Custom alloy |
|
|
| 21 |
PF1214-05-02-05 |
Swing arm shaft sleeve |
Custom alloy |
|
|
| 22 |
PF1214-08-07 |
main shaft |
Custom alloy |
|
|
Besides SHANGHAI SBM PF1214 Blow Bar , what other Blow Bars can we customize?
SAIKUANG holds a vast mold inventory of an extensive well-known HSI brands including: Hazemag, Mesto, Kleemann, Sandvik, Rockster, Rubble Master, Powerscreen, Evoquip, Striker, Keestrack, McCloskey, Eagle, Tesab, Finlay, KPI-JCI (ASTEC), SBM, Telsmith, Hartl, Lippmann, and others.
You can CONTACT US for a pattern list of the available blow bars. OR quote us the correct model numbers with the materials you require.
