Rubble Master Blow Bars

RUBBLE MASTER (RM) is an Austrian manufacturer headquartered in Linz, founded in 1991 by Gerald Hanisch. The company pioneered the concept of on-site recycling of construction and demolition waste, creating an entirely new category of compact mobile crushers designed for urban environments and operators with little to no material processing experience. Today, RUBBLE MASTER is recognized as a leading global manufacturer of high-performance mobile crushing and screening equipment, with products deployed across more than 110 countries in recycling, demolition, quarrying, mining, and construction applications.

The RUBBLE MASTER product line has evolved from its first compact crusher, the RM50, through successive generations including the RM60, RM70, RM80, and the technologically advanced RM100, establishing the company as a frontrunner in integrated mobile crushing systems. What sets RUBBLE MASTER apart is its unwavering focus on compact design, low fuel consumption, remote-controlled operation, and ease of use — principles that continue to guide every new model the company releases.

Rubble Master Blow Bar Models

Blow bars (also called hammers) are the primary wear components in horizontal shaft impact crushers. They strike incoming material and throw it against the impact wall, fracturing it into smaller particles. Selecting the correct blow bar for each RM model and application is critical for maximizing wear life and minimizing cost per ton.–31

We supply Rubble Master blow bars compatible with the full RM range:

Our Rubble Master blow bars are manufactured to OEM-equivalent dimensions and performance standards, ensuring perfect fitment and reliable operation across all compatible RM impact crushers.

Material Options for Rubble Master Blow Bars

The metallurgical composition of a blow bar determines its performance in specific applications. We offer Rubble Master blow bars in six primary material configurations:

1. Manganese Steel

Manganese steel, often referred to as Hadfield steel, is known for its high toughness and work-hardening behavior. It is an excellent choice for high-impact applications with mixed feed, including demolition waste containing rebar, tramp metal, and large uncrushable pieces. Its toughness helps prevent breakage, although its abrasion resistance is lower than high chrome or ceramic-reinforced materials.

2. Manganese Steel + TiC

This material combines a manganese steel matrix with titanium carbide (TiC) particles. The manganese steel provides impact toughness, while the TiC hard phase improves wear resistance. It is ideal for high-impact and abrasive applications, such as demolition recycling and mixed construction waste, where both shock resistance and wear life are required.

3. Martensitic Steel

Martensitic steel offers a good balance of toughness and wear resistance. It is widely used in concrete recycling and construction and demolition waste applications. Martensitic blow bars provide reliable performance in moderate abrasion conditions and are less brittle than high chrome alternatives.

4. Martensitic Steel + Ceramic

This configuration uses a martensitic steel body with embedded ceramic inserts. The ceramic inlays significantly improve abrasion resistance while the martensitic matrix maintains impact toughness. It is suitable for concrete recycling, asphalt recycling, and abrasive construction waste, delivering longer wear life than standard martensitic steel.

5. High Chrome

High chrome blow bars are engineered for highly abrasive applications such as asphalt crushing and natural rock processing. The high chromium content delivers superior wear resistance, but the material is more brittle than manganese or martensitic steel. High chrome bars are best suited for controlled feed conditions where the risk of uncrushable contaminants is minimized.

6. High Chrome + Ceramic

This premium configuration combines the hardness of high chrome with the extended wear life of ceramic inserts. These bars are particularly effective in secondary and tertiary crushing, including asphalt processing and hard natural stone reduction. As with standard high chrome bars, feed size control and contaminant exclusion are recommended for optimal performance.

SAIKUANG Casting Advantages for Rubble Master Blow Bars

Why Choose Saikuang for Rubble Master Blow Bars

At Saikuang Casting, we are a leading manufacturer of premium-quality blow bars, impact plates, and side liners for impact crushers. As one of the few foundries worldwide capable of producing reliable MMC (Metal Matrix Composite) wear castings — especially impact crusher wear parts with ceramic inserts — we bring advanced materials engineering to every Rubble Master blow bar we produce.

OEM-Equivalent Quality

We specialize in producing OEM-equivalent blow bars and developing customized alloy solutions for primary and secondary crushing applications. Our Rubble Master blow bars are manufactured under a strict quality control system to ensure 100% compliance with original dimensions and performance standards, effectively minimizing equipment downtime and maximizing productivity.

Customized Material Solutions

Every crushing operation is different. We work closely with our customers to develop customized material solutions based on their specific working conditions — whether that means optimizing ceramic particle distribution, adjusting alloy composition, or tailoring hardness-to-toughness ratios for a particular feed material. Our ceramic composite materials have been reported by customers to deliver 1.5× to 10× the wear life of conventional alternatives in demanding crushing environments.

Full Compatibility Guarantee

Saikuang Casting guarantees 100% part adaptability for both OEM replacement parts and custom products. Our Rubble Master blow bars are verified for compatibility with original specifications, ensuring seamless installation and reliable performance from the first ton crushed.

Global Supply Capability

As an international supplier, Saikuang Casting offers flexible delivery options and comprehensive logistics support to meet project timelines and operational requirements worldwide. We have extensive experience exporting impact crusher wear parts to markets across Africa, Europe, and the Americas, ensuring timely and secure delivery regardless of location.

Comprehensive Wear Parts Range

Beyond Rubble Master blow bars, we manufacture a full suite of impact crusher wear parts including impact plates, side liners, anvils, breakers, and cutter bars — all produced with the same commitment to material excellence and dimensional precision.

Contact Us

Whether you operate an RM 60 for small-scale recycling or an RM 120X for high-capacity aggregate production, Saikuang Casting has the Rubble Master blow bars you need — in the material, configuration, and quantity that match your application.

Get in touch today to discuss your requirements, request a quote, or explore our customized material solutions for Rubble Master impact crushers.
