Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts
Saikuang Casting is a leading manufacturer of premium-quality Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts for Metso Barmac B7150SE (840STD rotor) VSI Crusher.
We supply Key Replacement Parts,including: Bare Rotor, Rotor Tip, Set Trail Plate, Set Long Backup Tip Set, Top Wear Plate (Lipped), Bottom Wear Plate (Lipped), Bolt Set ,Bolt ,Cavity Wear Plate Outer, Upper Wear Plate, Lower Wear Plate, Feed Eye Ring, Feed Tub, Distributor Plate, etc.
Our wear parts are manufactured using:Chrome iron，Ceramic chromium iron，Manganese steel，Titanium carbide (TiC) reinforced manganese steel，Martensitic， Ceramic Martensitic，All of these materials are renowned for their excellent wear resistance and operational stability.
“All brand names, model names or marks are property of their respective manufacturers. SAIKUANG and OEMs. These terms are used for identification purposes only and are not intended to indicate affiliation with or approval by the OEM. All parts are manufactured, warrantied by SAIKUANG and are not manufactured, purchased or warrantied by the OEM.”
Contact us
Please leave your specific needs and contact information, and the staff will contact you as soon as possible!
Metso Barmac B7150SE (840STD Rotor) VSI Crusher Spare Wear Parts
The Metso Barmac B7150SE VSI Crusher is a world-renowned vertical shaft impact crusher widely used in quarrying, aggregate production, manufactured sand manufacturing, and construction waste recycling. It can operate in both rock-on-rock and rock-on-metal modes to produce high-quality cubical aggregates and manufactured sand. The B7150SE is a popular medium-large VSI model equipped with an 840STD rotor for high-capacity production. The 840STD rotor is the standard configuration for this model, featuring a rotor diameter of 840 mm and a maximum feed size of 45 mm (up to 57 mm depending on the application).
When it comes to keeping your Barmac B7150SE running at peak efficiency, choosing the right Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts is essential. Since VSI crushers work at high rotor speed — typically with material ejection speeds of 45–65 m/s (1250–1800 RPM) for the 840 rotor — internal components endure continuous high-velocity impact and abrasive wear. High-quality Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts are critical to stabilize output, reduce unplanned downtime, and lower total operation cost.
Metso Barmac B7150SE (840STD Rotor) VSI Crusher Spare Wear Parts List
The B7150SE with 840STD rotor has a complete set of consumable components. The most frequently replaced Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts are listed below:
No.
Part Number
Description
Qty
1
B96334105L
Bare Rotor
1
2
B96394049O
Rotor Tip Set
2
3
B96394055B
Trail Plate Set
1
4
B96394060B
Long Backup Tip Set
1
5
B96334170C
Top Wear Plate (Lipped)
1
6
B96334180A
Bottom Wear Plate (Lipped)
1
7
B96394150O/B
Bolt Set
3
8
B963940425A
Bolt
1
9
B96394150N
Cavity Wear Plate Outer
4
10
B96334135A
Upper Wear Plate
1
11
B96334140A
Lower Wear Plate
1
12
B96334030E
Feed Eye Ring
1
13
B962S7040B
Feed Tube
1
14
B96394120E
Distributor Plate
1
These Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts work together to ensure even material distribution, protect the rotor and crushing chamber, and maintain consistent product gradation. The tip plate set is the core rotor wear part, suffering the strongest impact and abrasion during operation. The distributor plate and bolt secure the rotor feed system. The upper and lower wear plates protect the rotor body, while the outer wear plate and wear plate set shield the crushing chamber. The trail plate and backup tip set further extend the service life of the rotor and chamber components.
Their wear rates vary depending on feed material hardness, abrasiveness, and operating parameters, but timely replacement of worn Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts is essential to avoid reduced capacity and damage to non-wearing components.
Feed Tube-Metso Barmac B7150Se (840Std Rotor) Vsi Crusher Spare Wear Parts
Material Selection for Metso Barmac B7150SE (840STD Rotor) VSI Crusher Spare Wear Parts
SAIKUANG is a professional manufacturer of aftermarket VSI crusher wear parts, specializing in the production of fully compatible Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts. We offer three material options to match different customer working conditions. All products undergo strict heat treatment, hardness testing, dimensional inspection, and non-destructive flaw detection to eliminate casting defects, ensure stable dynamic balance, and deliver excellent wear resistance, completely matching the working performance of original parts.
Material Grade
Key Characteristics
High Chrome 26%
Standard high-chrome material with 26% chromium content. Balanced wear resistance and impact toughness, fine and uniform internal metallographic structure, strong resistance to particle scratching and abrasive wear. Suitable for medium-abrasive materials such as limestone, river pebble, recycled concrete, and ordinary aggregate. Cost-effective with stable service life.
High Chrome 26% with Ceramic
Based on the 26% high-chrome matrix, reinforced with embedded ceramic particles. Combines the high toughness of the metal matrix with the ultra-high wear resistance of ceramic. Mainly used for crushing high-hardness materials such as granite, basalt, and quartz stone. Delivers significantly longer service life and reduces frequent replacement and production shutdown loss.
High Chrome 26% with Tungsten Carbide
Further enhances the 26% high-chrome matrix with tungsten carbide reinforcement. Tungsten carbide provides extreme hardness and excellent anti-abrasion performance, ideal for the most demanding high-abrasion and high-impact applications. Particularly suitable for crushing hard rock, ore, and other highly abrasive materials. Offers the longest wear life among the three options, minimizing downtime and maximizing productivity.
The hardness of these materials typically reaches HRC 58–63 for high chrome grades. The ceramic and tungsten carbide reinforced options provide even greater wear resistance, making them ideal for high-abrasion applications where standard materials would wear out quickly.
SAIKUANG — Your Reliable Supplier of Metso Barmac B7150SE (840STD Rotor) VSI Crusher Spare Wear Parts
SAIKUANG Casting is a leading manufacturer of premium-quality Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts for Metso Barmac B7150SE VSI crushers. Our facility covers 60 acres with an annual production capacity of 16,000 tons, and we have extensive experience in producing ceramic and alloy steel castings. We supply key replacement Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts including bare rotors, rotor tip sets, short backup tip sets, trail plates, long backup tip sets, top and bottom wear plates, bolt sets, cavity wear plates (outer and middle), feed eye rings, upper and lower wear plates, feed tubes, and distributor plates.
For Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts, SAIKUANG offers:
OEM-Level Fit:SAIKUANG guarantees 100% part adaptability. Our Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts are engineered to match original dimensions and mounting configurations, ensuring correct seating and material flow without the need for modification.
Premium Materials:We supply VSI wear parts in High Chrome 26%, High Chrome 26% with Ceramic, and High Chrome 26% with Tungsten Carbide grades. Our VSI parts cover a wide range of popular models, including Metso Barmac B Series (B6150SE, B7150SE, B9100SE), Sandvik CV Series, Trio TV Series, and Terex Canica Series.
Superior Wear Solutions:SAIKUANG offers better material solutions than standard OEM specifications. Our ceramic and tungsten carbide reinforced options provide significantly longer service life, reducing replacement frequency and lowering cost per ton.
Cost-Effective Solution:As an aftermarket supplier, SAIKUANG provides competitive pricing without compromising on quality.
Fast Delivery:We maintain a large inventory of common VSI wear parts to minimize customer downtime and support continuous production.
Contact Us
If you are looking for high-quality Metso Barmac B7150SE (840STD rotor) VSI Crusher Spare Wear Parts — including bare rotors, rotor tip sets, short backup tip sets, trail plates, long backup tip sets, top and bottom wear plates, bolt sets, cavity wear plates (outer and middle), feed eye rings, upper and lower wear plates, feed tubes, and distributor plates — SAIKUANG is ready to provide reliable products and excellent service. Contact us today for a quotation or technical consultation.
