What is Crusher Jaw Plates?
A crusher jaw plate protects and supports the jaw crusher. A jaw plate is the most frequently changed wear part, so ensuring a quality graded jaw crusher is crucial. Jaw plates, also called ‘jaw dies, ‘ are often made of a mixture of graded composite or high-resistance steel.
Working Principles
Usually, in a conventional crushing operation, there are two jaw plates of moveable and stationary jaws. These jaws are located on the opposite sides of the crushing chambers. To fully segment and fracture the material, the moveable jaw plate works reciprocally to press the material against the fixed plate. The material continues to be crushed on the fixed jaw until refined enough to get through the jaw gap.
Jaw Plates for Leading Crusher Manufacturers
1. Metso
Core Features of Original Crusher Jaw Plates
Metso Nordberg C-series jaw plates adopt optimized chamber curve design. Multiple tooth profile options are available, including Quarry, Superteeth, Super Grip and MX composite liners. Standard material adopts Mn13Cr2 high manganese steel. Dimensional tolerance is strictly unified globally. Many models support reversible installation for extended service cycle. The tooth structure is designed to improve material gripping, reduce slabby finished aggregates.
Mainstream Applicable Models: C80, C96, C106, C120, C130, C160; Lokotrack LT series mobile jaw host.
Good At: Large stationary quarry production lines, open-pit hard rock mining, granite, basalt and high-abrasion ores. Widely deployed in global large-scale long-term fixed crushing projects.
2. Sandvik
Core Features of Original Crusher Jaw Plates
Matching CJ stationary jaw and QJ mobile jaw series. Equipped with diversified tooth patterns: Corrugated, Coarse Corrugated, Wide Teeth, Optitooth patented liners. Independent alloy material grades (M1/M2/M8) to match impact resistance and abrasion resistance demands. Strict casting precision to guarantee assembly clearance. Most models feature exclusive hole position layout with low interchangeability with other brands.
Mainstream Applicable Models: CJ408, CJ411, CJ613; QJ241, QJ341, QJ351 mobile crushers.
Good At: European & Australian aggregate quarries, metal mine primary crushing, construction waste recycling. Favored for medium-hard rock and strict aggregate shape requirements.
3. Terex (Powerscreen & Finlay)
Core Features of Original Crusher Jaw Plates
Serving CRJ stationary jaw and Powerscreen / Finlay mobile jaw units. Jaw plate structure focuses on balanced toughness, adapted to mixed incoming materials. Standard manganese steel formulation focuses on comprehensive cost control. Multiple updated machine versions lead to iterative changes of jaw plate drawings on the same model.
Mainstream Applicable Models: Premiertrak 400X, 450, 600; Finlay J-1170, J-1175, J-1280; CRJ3042, CRJ3255.
Good At: Mobile demolition waste recycling, on-site construction crushing, small and medium-sized temporary quarry projects. Popular in UK, Oceania and Southeast Asia mobile crushing markets.
4. Kleemann (Wirtgen Group)
Core Features of Original Crusher Jaw Plates
Designed for MC series tracked mobile jaw crushers. Original liners mostly adopt Mn18 high manganese steel formula, oriented to continuous heavy impact working conditions. Tooth height and spacing optimized for stable continuous operation. High requirement for casting density to avoid crack risk under frequent heavy loading.
Mainstream Applicable Models: MC100i EVO, MC110i EVO2, MC120 PRO.
Good At: European highway infrastructure projects, high-duty continuous mobile crushing, medium & large size hard rock temporary production sites. Dominant market share in Western Europe.
5. McCloskey
Core Features of Original Crusher Jaw Plates
J-series mobile jaw crushers partly adopt Metso-origin jaw chambers, while self-developed models have independent jaw plate drawings. Jaw plate structure emphasizes convenient on-site replacement. Material configuration balances impact resistance and wear resistance to adapt to frequently transferred job sites.
Mainstream Applicable Models: J40, J45, J50, J60 tracked jaw crushers.
Good At: North America, Australia aggregate quarries, remote site mobile crushing, demolition recycling projects. Well recognized in rental crushing fleet market.
About Saikuang’s Crusher Jaw Plates
As a global wear resistant solution partner in the fields of mining and construction waste recycling, Saikuang has specially developed high impact-resistant tooth plates for the primary crushing conditions of jaw crushers. Addressing the severe challenges posed by high-hardness materials such as granite and basalt, as well as the frequent start-ups and shutdowns of mobile crushing stations, we can provide personalized product services based on different working conditions.
1. Core Advantages of SAIKUANG Crusher Jaw Plates
- Diversified Wear-resistant Material Options
We provide three mainstream alloy high manganese steel grades: MN13CR2, MN18CR2 and MN22CR2, matching different load and abrasion conditions.
- Customizable Tooth Profile Design
We tailor tooth shape, tooth height and size according to customers’ raw material, feeding size and production demands, lifting crushing efficiency and extending service life.
- Ultra Wear-resistant TiC Composite Solution
Titanium Carbide embedded jaw plates are available for heavy-duty hard rock mining. Compared with ordinary manganese jaw plates, their service life is 3–5 times longer, effectively cutting frequent replacement downtime. This product has stable market feedback in Europe, Australia and Africa.
- One-stop Supporting Parts Service
Apart from jaw liners, we also supply side cheek plates, wedges, toggle plates, bolts and matching hardware, realizing full-set jaw crusher wear parts procurement for clients.
2.Manganese Jaw plate
Manganese Jaw Liner, Jaw plate exhibits distinct performance characteristics and application scopes.the manganese content increases (from MN13Cr2 to MN22Cr2), the overall strength and wear resistance
- MN13Cr2:Applicability: Suitable for jaw liner subjected to moderate load requirements, particularly in cost-sensitive industrial applications.Application Scope: Commonly used in medium-wear levels of jaw crushers, ideal for scenarios requiring high wearing with moderate demands on durability and strength.
- MN18Cr2:Performance Attributes: Offers enhanced wear resistance and strength compared to MN13Cr2.Applicability: Appropriate for jaw plate in moderate to high overload conditions, suitable for industries requiring increased durability and load-bearing capacity.
- MN22Cr2:Performance Attributes: Features the highest wear resistance and strength among the three grades, designed for extreme overload scenarios.Application Scope: Primarily used in high-wear environments such as mining equipment or industrial applications with high abrasive loading requirements. Ideal for scenarios needing exceptional wear resistance and impact resistance.
3.Titanium Carbide (TiC) Jaw Plates
Product Concept: TiC-embedded jaw plates utilize advanced composite technology to significantly extend wear part service life in high-load crushing applications. By dispersing titanium carbide particles within the base metal matrix, these plates deliver superior performance in demanding mining and aggregate operations.
Performance Benefits
-
3-5x longer service life compared to standard manganese steel
-
Reduced downtime for component replacement
-
Improved crushing efficiency in hard rock applications
-
Proven results in European, Australian and African markets
These advanced jaw plates represent the optimal solution for operations seeking to maximize equipment uptime and reduce long-term operating costs.
4. Wide Compatibility for Global Mainstream Crusher Brands
Covered Main Brands & Series
- Metso: Nordberg C Series, Lokotrack LT Series
- Sandvik: CJ, CM, JM, UJ, QJ mobile series
- Terex: Powerscreen Premiertrak, Finlay J series, Cedarapids CRJ/JW series
- Kleemann: MC EVO & PRO mobile jaw crushers
- McCloskey, Telsmith, Lippmann, Komatsu, Liming, SBM and other Chinese domestic crusher models
Customers can send OEM part numbers or crusher model drawings to get accurate quotations. Our technical team will recommend matched material grade and tooth structure based on your actual crushing conditions.
