TRIO TC362 Cone Crusher Parts: TC362-1002 Shaft & TC362-1003 Head Body Shipped to South America
The TRIO TC series cone crusher is its classic heavy-duty model. The TC362 cone crusher features a reliable moving shaft design, with TC362-1002 Shaft and TC362-1003 Head Body as the core load-bearing components.
SAIKUANG Casting is a professional manufacturer of crusher replacement parts and wear-resistant castings. Recently, we finished the shipment of TRIO TC362 Cone Crusher Parts to customers across South America，includes TC362-1002 Shaft and TC362-1003 Head Body.
These two components are core load-bearing parts exclusively designed for TRIO TC362 cone crusher. In crushing production, they bear heavy torsion, frequent impact and long-cycle fatigue loads. Damaged shafts or head bodies will lead to full-line shutdown and heavy production losses.
Our TC362-1002 Shaft and TC362-1003 Head Body adopt high-strength alloy steel for forging. Standard quenching and tempering heat treatment are applied to stabilize internal metal structure. The finished parts feature excellent anti-fatigue and anti-deformation performance, resisting cracking under harsh mining conditions.
All products go through full quality checks before shipment:
- Raw material chemical analysis
- Precision dimensional tolerance testing
- Surface hardness inspection
- Non-destructive flaw detection
Our parts fully comply with OEM original drawing standards and can be directly interchanged. South American clients can install them without secondary modification, cutting maintenance downtime and operational costs.
TRIO TC362 Cone Crusher Parts & More Optional Crusher Parts
SAIKUANG Casting boasts abundant mold resources and full coverage of crusher models., We has thousands of molds crusher brands: TRIO, Metso, Sandvik, Terex and more.
Besides TRIO TC362 Cone Crusher Parts ，Complete spare parts for TRIO TC36, TC51, TC66 and TC84 are in regular stock:Cone crusher mantle, cone crusher socket liner, cone crusher bowl liners, concave, cone crusher cone head, cone crusher eccentrci, eccentric bushing, head ball, cone crusher countershaft bushing, cone crusher main shaft, bottom shell, dust seal ring, cone crusher main frame, main frame liner, cone crusher pinion, pinion bevel gear, cone crusher thrust bearing, torch ring, and etc.
TRIO TC36 Cone Crusher Parts List:
| Part No. | Part name |
| TC360 1000 | Main component |
| TC360 1001 | Spider guard |
| TC360 1002 | Main frame |
| TC360 1003 | Frame Bushing |
| TC360 1004 | Frame pin |
| TC360 1005 | Washer |
| TC360 1006 | Main Frame Cap |
| TC360 1007 | Pin |
| TC360 1008 | Shims |
| TC360 1009 | Upper Bearing Plate |
| TC360 1010 | Lower Bearing Plate |
| TC360 1011 | Bushing |
| TC360 1012 | Keyway |
| TC360 1013 | Washer |
| TC360 1014 | Auxiliary welding |
| TC360 2000 | Countershaft assembly |
| TC360 2001 | Key |
| TC360 2002 | Pinion |
| TC360 2003 | Wearing Plate |
| TC360 2004 | Countershaft bracket |
| TC360 2005 | Countershaft bushing |
| TC360 2006 | Countershaft guard |
| TC360 2007 | Countershaft |
| TC360 2008 | Oil Flinger |
| TC360 2009 | Washer |
| TC360 2010 | Oil collector |
| TC360 2011 | Plunger ring |
| TC360 2012 | Large taper bushing |
| TC360 2013 | Large pulley |
| TC360 2014 | Welding pipe |
| TC360 2015 | Adjustment pad |
| TC360 3000 | Eccentric Assembly |
| TC360 3001 | Gear |
| TC360 3002 | Eccentric |
| TC360 3003 | Main shaft bushing |
| TC360 3004 | Gear key |
| TC360 4000 | Socket assembly |
| TC360 4001 | Sealing ring |
| TC360 4002 | Key |
| TC360 4003 | Retaining Ring |
| TC360 4004 | Socket liner |
| TC360 4005 | Spring |
| TC360 4006 | Spring bushing |
| TC360 4007 | Socket |
| TC360 5000 | Adjustment bushing Assembly |
| TC360 5001 | Adjustment bushing |
| TC360 5010 | Bowl Assembly |
| TC360 5011 | Rubber sealing ring |
| TC360 5012 | Press Board |
| TC360 5013 | Adjustment Cap |
| TC360 5023 | Press Board |
| TC360 7030 | Bushing |
| TC362 1000 | Head assembly |
| TC362 1001 | Damping sleeve |
| TC362 1002 | Main shaft |
| TC362 1003 | Head |
| TC362 1004 | Mantle |
| TC362 1005 | Sleeve |
| TC362 1006 | Torch ring |
| TC362 1010 | Main shaft cap |
| TC362 2000 | Bowl Assembly |
| TC362 2001 | Bowl |
| TC362 2002 | Bowl liner |
| TC361 2002 | Bowl liner |
| TC363 2002 | Bowl liner |
| TC363 2040 | Fill block |
| TC362 2003 | U bolt |
| TC362 2004 | Lower washer |
| TC362 2005 | Rubber washer |
| TC362 2006 | Upper washer |
| TC362 2007 | Locking washer |
| TC362 2008 | Cover Plate |
| TC362 2009 | Washer |
| TC362 2010 | Washer |
| TC362 2011 | Washer |
| TC362 2012 | Lock screw |
| TC362 2013 | Wedge |
| TC362 2020 | Hopper |
| TC362 2030 | Receiving cone |
| TC365 1002 | Head |
| TC365 1003 | Mantle |
| TC365 1004 | Sleeve |
| TC365 1005 | Torch ring |
| TC365 1006 | Main shaft cap |
| TC365 1008 | Tapper plate |
| TC365 2000 | Bowl Assembly |
| TC365 2001 | Bowl |
| TC365 2002 | Bowl liner |
| TC365 2040 | Fill block |
| TC366 2002 | Bowl liner |
| TC366 2040 | Fill block |
| TC366 2041 | Arcuate plate |
| TC367 2002 | Bowl liner |
| TC367 2040 | Fill block |
| TC367 2041 | Arcuate plate |
If you have any intresting in TRIO TC362 Cone Crusher Parts or TRIO TC36, TC51, TC66 and TC84 cone crusher parts , welcome to CONTACT US .
For more product photos, processing videos and technical parameters, visit our official YouTube channel: https://www.youtube.com/@SaikuangMachinery
Your Reliable Partner for Crusher Spare Parts SAIKUANG Casting
