Saikuang Casting is a leading manufacturer of premium-quality blow bars, impact plates, and side liners for SHANGHAI SBM PFW1318II Blow Bar series impact crushers.
We specialize in producing OEM-equivalent blow bars and developing customized alloy solutions for primary and secondary crushers to effectively minimize equipment downtime.
Our wear parts are manufactured using:Chrome iron，Ceramic chromium iron，Manganese steel，Titanium carbide (TiC) reinforced manganese steel，Martensitic， Ceramic Martensitic，All of these materials are renowned for their excellent wear resistance and operational stability.
“All brand names, model names or marks are property of their respective manufacturers. SAIKUANG and OEMs. These terms are used for identification purposes only and are not intended to indicate affiliation with or approval by the OEM. All parts are manufactured, warrantied by SAIKUANG and are not manufactured, purchased or warrantied by the OEM.”
Contact us
Please leave your specific needs and contact information, and the staff will contact you as soon as possible!
Exclusive SHANGHAI SBM PFW1318II Blow Bar Introduction
What is PFW1318II Impact Crusher?
The PFW318II Impact Crusher is a crushing machinery that uses impact energy to crush materials. When the material enters the action zone of the plate hammer, it is crushed by the high-speed impact of the plate hammer and thrown towards the counterattack device installed above the rotor for further crushing. Then, it bounces back from the counterattack broken lining plate to the action zone of the plate hammer for re crushing. This process is repeated until the material is crushed to the desired particle size and discharged from the lower part of the machine.
Adjusting the gap between the counterattack frame and the rotor frame can achieve the goal of changing the particle size and shape of the material. This machine adopts a spring safety device after the counterattack plate. When non broken objects enter the crushing chamber, the front and rear counterattack frames retreat, and the non broken objects are discharged from the machine.
Saikuang Casting: HANGHAI SBM PFW1318II Blow Bar
As the core component of the crushing process, the HANGHAI SBM PFW1318II Blow Bar is engineered for performance and durability. These are thick slabs of metal, typically manufactured from high-chromium alloys, specifically designed to break down abrasive materials like asphalt, concrete, and limestone.
The material selection for the HANGHAI SBM PFW1318II Blow Bar is critical. It is made from advanced chrome mixtures chosen for their exceptional hardness and wear resistance, ensuring a long service life even under the most demanding conditions. When installed on the rotor, the HANGHAI SBM PFW1318II Blow Bar rotates at tremendous speeds, delivering the repeated, violent impacts necessary for effective size reduction.
To maintain optimal crusher performance, using high-quality, precisely matched replacement parts is essential. The HANGHAI SBM PFW1318II Blow Bar, along with other wear parts like impact plates and liners, can be sourced from specialized suppliers like SAIKUANG Casting. These replacement components are manufactured under strict quality control systems, guaranteeing 100% adherence to the original dimensions and performance standards of the genuine HANGHAI SBM PFW1318II Blow Bar, ensuring seamless integration and reliable operation.
HANGHAI SBM PFW1318II Impact Crusher Parts List
PFW1318Ⅱ Impact Crusher Parts List
Series
Part Number
Name
Material
PCS
Notices
1
PFC1318S-01-1
Motor pulley
HT
2
PFC1318S-02-1
wear plate
ZGMn13
3
PFC1318S-02-3
wear plate
ZGMn13
4
PFC1318S-02-4
wear plate
ZGMn13
5
PFC1318S-02-5
wear plate
ZGMn13
6
PFC1318S-02-6
wear plate
ZGMn13
7
PFC1318S-03-1
Main spindle wheel
HT
8
PFC1318-03-3
blow bar
CR
9
PFC1318-03-4
blow bar
CR
10
PFC1214-03-14
wedge
CS
11
PFC1315S-05-1
wear plate
ZGMn13
12
PFC1315S-05-2
wear plate
ZGMn13
13
PFC1315S-05-3
wear plate
ZGMn13
14
PFC1315-02–6
wear plate
ZGMn13
15
PFC1315S-05-4
wear plate
ZGMn13
16
PFC1315S-07-2
impact plate
ZGMn13
Besides HANGHAI SBM PFW1318II Blow Bar , what other Blow Bars can we customize?
SAIKUANG holds a vast mold inventory of an extensive well-known HSI brands including: Hazemag, Mesto, Kleemann, Sandvik, Rockster, Rubble Master, Powerscreen, Evoquip, Striker, Keestrack, McCloskey, Eagle, Tesab, Finlay, KPI-JCI (ASTEC), SBM, Telsmith, Hartl, Lippmann, and others.
You can CONTACT US for a pattern list of the available blow bars. OR quote us the correct model numbers with the materials you require.
