Saikuang Casting is a leading manufacturer of premium-quality blow bars, impact plates, and side liners for SHANGHAI SBM PFW1214III Blow Bar series impact crushers.
We specialize in producing OEM-equivalent blow bars and developing customized alloy solutions for primary and secondary crushers to effectively minimize equipment downtime.
Our wear parts are manufactured using:Chrome iron，Ceramic chromium iron，Manganese steel，Titanium carbide (TiC) reinforced manganese steel，Martensitic， Ceramic Martensitic，All of these materials are renowned for their excellent wear resistance and operational stability.
“All brand names, model names or marks are property of their respective manufacturers. SAIKUANG and OEMs. These terms are used for identification purposes only and are not intended to indicate affiliation with or approval by the OEM. All parts are manufactured, warrantied by SAIKUANG and are not manufactured, purchased or warrantied by the OEM.”
Contact us
Please leave your specific needs and contact information, and the staff will contact you as soon as possible!
Exclusive SHANGHAI SBM PFW1214III Blow Bar Introduction
What is PFW1214III Impact Crusher?
The PFW1214III Impact Crusher used in industrial sectors such as metallurgy, mining, cement, chemical industry, refractory materials, and ceramics, it is widely used in highway construction, water conservancy engineering, construction gravel, and machine-made sand processing. It is very suitable for coarse, medium, and fine crushing operations of various soft and medium hard ores. The leading manufacturers are Shanghai SBM and Henan Limining.
Saikuang Casting: SHANGHAI SBM PFW214III Blow Bar
As the core component of the crushing process, the SHANGHAI SBM PFW1214III Blow Bar is engineered for performance and durability. These are thick slabs of metal, typically manufactured from high-chromium alloys, specifically designed to break down abrasive materials like asphalt, concrete, and limestone.
The material selection for the SHANGHAI SBM PFW1214III Blow Bar is critical. It is made from advanced chrome mixtures chosen for their exceptional hardness and wear resistance, ensuring a long service life even under the most demanding conditions. When installed on the rotor, the SHANGHAI SBM PFW1214III Blow Bar rotates at tremendous speeds, delivering the repeated, violent impacts necessary for effective size reduction.
To maintain optimal crusher performance, using high-quality, precisely matched replacement parts is essential. The SHANGHAI SBM PFW1214III Blow Bar, along with other wear parts like impact plates and liners, can be sourced from specialized suppliers like SAIKUANG Casting. These replacement components are manufactured under strict quality control systems, guaranteeing 100% adherence to the original dimensions and performance standards of the genuine SHANGHAI SBM PFW1214III Blow Bar, ensuring seamless integration and reliable operation.
SHANGHAI SBM PFW1214III Impact Crusher Parts List
PFW1214III Impact Crusher Parts List
Series
Part Number
Name
Material
PCS
Notices
1
PFC1214-03-14
blow bar
高铬
8
2
PFC1214-07-3
impact plate
ZGMn13
20
3
PFC1214-07-7
impact plate
ZGMn13
15
4
PFC1214-03-12
Main wheel
1
5
PFC1214-01-1
motor pulley
1
6
PFC1214-03-1
Cover
1
7
PFC1214-03-10
Transparent coverII
1
8
PFC1214-03-4
bearing housing
ZG
2
9
PFC1214-08-8
Adjusting nut
ZG
4
10
PFC1214-03-15
wedge
ZG
16
11
PFC1214-03-16
plywood
ZG
32
12
PFC1214-05-1
wear plate
ZGMn13
2
13
PFC1214-05-2
wear plate
ZGMn13
2
14
PFC1214-05-3
wear plate
ZGMn13
2
15
PFC1214-05-4
wear plate
ZGMn13
32
16
PFC1214-05-5
wear plate
ZGMn13
6
17
PFC1214-05-6
wear plate
ZGMn13
2
18
PFC1214-05-11
wear plate
ZGMn13
4
19
PFC1214-05-12
wear plate
ZGMn13
2
20
PFC1214-02-6
Front Liner
ZGMn13
16
21
PFC1214-02-7
Front Liner
ZGMn13
3
22
PFC1214-02-8
Front Liner
ZGMn13
16
23
PFC1214-03-8
main shaft
40Cr
1
Sbm-Pfw1214Iii-Blow-Bar
Besides SHANGHAI SBM PF1214III Blow Bar , what other Blow Bars can we customize?
SAIKUANG holds a vast mold inventory of an extensive well-known HSI brands including: Hazemag, Mesto, Kleemann, Sandvik, Rockster, Rubble Master, Powerscreen, Evoquip, Striker, Keestrack, McCloskey, Eagle, Tesab, Finlay, KPI-JCI (ASTEC), SBM, Telsmith, Hartl, Lippmann, and others.
You can CONTACT US for a pattern list of the available blow bars. OR quote us the correct model numbers with the materials you require.
