Saikuang Casting is a leading manufacturer of premium-quality blow bars, impact plates, and side liners for HENAN LIMING PFW1318Ⅲ Blow Bar series impact crushers.
We specialize in producing OEM-equivalent blow bars and developing customized alloy solutions for primary and secondary crushers to effectively minimize equipment downtime.
Our wear parts are manufactured using:Chrome iron，Ceramic chromium iron，Manganese steel，Titanium carbide (TiC) reinforced manganese steel，Martensitic， Ceramic Martensitic，All of these materials are renowned for their excellent wear resistance and operational stability.
“All brand names, model names or marks are property of their respective manufacturers. SAIKUANG and OEMs. These terms are used for identification purposes only and are not intended to indicate affiliation with or approval by the OEM. All parts are manufactured, warrantied by SAIKUANG and are not manufactured, purchased or warrantied by the OEM.”
Contact us
Please leave your specific needs and contact information, and the staff will contact you as soon as possible!
Excellent HENAN LIMING PFW1318Ⅲ Blow Bar Introduction
What is PFW1318Ⅲ Impact Crusher?
The PFW1318Ⅲ Impact Crusher is a crushing machinery that uses impact energy to crush materials. When the material enters the action zone of the plate hammer, it is crushed by the high-speed impact of the plate hammer and thrown towards the counterattack device installed above the rotor for further crushing. Then, it bounces back from the counterattack broken lining plate to the action zone of the plate hammer for re crushing. This process is repeated until the material is crushed to the desired particle size and discharged from the lower part of the machine.
Adjusting the gap between the counterattack frame and the rotor frame can achieve the goal of changing the particle size and shape of the material. This machine adopts a spring safety device after the counterattack plate. When non broken objects enter the crushing chamber, the front and rear counterattack frames retreat, and the non broken objects are discharged from the machine.
Saikuang Casting: HENAN LIMING PFW1318Ⅲ Blow Bar
As the core component of the crushing process, the HENAN LIMING PFW1318Ⅲ Blow Bar is engineered for performance and durability. These are thick slabs of metal, typically manufactured from high-chromium alloys, specifically designed to break down abrasive materials like asphalt, concrete, and limestone.
The material selection for the HENAN LIMING PFW1318Ⅲ Blow Bar is critical. It is made from advanced chrome mixtures chosen for their exceptional hardness and wear resistance, ensuring a long service life even under the most demanding conditions. When installed on the rotor, the HENAN LIMING PFW1318Ⅲ Blow Bar rotates at tremendous speeds, delivering the repeated, violent impacts necessary for effective size reduction.
To maintain optimal crusher performance, using high-quality, precisely matched replacement parts is essential. The HENAN LIMING PFW1318Ⅲ Blow Bar, along with other wear parts like impact plates and liners, can be sourced from specialized suppliers like SAIKUANG Casting. These replacement components are manufactured under strict quality control systems, guaranteeing 100% adherence to the original dimensions and performance standards of the genuine HENAN LIMING PFW1318Ⅲ Blow Bar, ensuring seamless integration and reliable operation.
HENAN LIMING PFW1318Ⅲ Impact Crusher Parts List
PFW1318Ⅲ Impact Crusher Parts List
Series
Part Number
Name
Material
PCS
Notices
1
PFC1315-01-1
Motor pulley
HT
2
PFC1315-03-5
transparent cover
HT
3
PFC1315-03-9
transparent cover
HT
4
PFC1315-03-11
Main spindle wheel
HT
5
PFC1315-03-1
blind cover
HT
6
PFC1315-03-2
cover pressing
Q235
7
PFC1315-03-6
bushing
45#
8
PFC1315-03-10
bushing
45#
9
PFC1315-03-4
bearing housing
ZG
10
PFC1318-02-2
wear plate
ZGMn13Cr2
11
PFC1318-02-3
wear plate
ZGMn13Cr2
12
PFC1318-02-4
wear plate
ZGMn13Cr2
13
PFC1315-05-1
wear plate
ZGMn13Cr2
14
PFC1315-05-2
wear plate
ZGMn13Cr2
15
PFC1315-05-3
wear plate
ZGMn13Cr2
16
PFC1214-05-4
wear plate
ZGMn13Cr2
17
PFC1214-05-5
wear plate
ZGMn13Cr2
18
PFC1315-05-9
wear plate
ZGMn13Cr2
19
PFC1315-07-2
impact plate
ZGMn13Cr2
20
PFC1318-07-3
impact plate
ZGMn13Cr2
21
PFC1318-03-3
blow bar
KmTBGr26
22
PFC1318-03-4
blow bar
KmTBGr26
23
main shaft
40CR
Besides HENAN LIMING PFW1318Ⅲ Blow Bar , what other Blow Bars can we customize?
SAIKUANG holds a vast mold inventory of an extensive well-known HSI brands including: Hazemag, Mesto, Kleemann, Sandvik, Rockster, Rubble Master, Powerscreen, Evoquip, Striker, Keestrack, McCloskey, Eagle, Tesab, Finlay, KPI-JCI (ASTEC), SBM, Telsmith, Hartl, Lippmann, and others.
You can CONTACT US for a pattern list of the available blow bars. OR quote us the correct model numbers with the materials you require.
