Magotteaux & MAG2100 Anvil
Magotteaux is a leading global manufacturer of crusher wear parts and professional VSI crushing equipment, with over a century of industrial experience and advanced metallurgical technology. The Mag’Impact 2100 (MAG2100) is one of its most popular mid‑range VSI crushers, widely used in aggregate shaping, manufactured sand production, mineral crushing and construction waste recycling.
The MAG2100 Anvil (core part number: QCA054) is the core stationary wear component inside the MAG2100 VSI crushing chamber. It directly determines crushing efficiency, the cubicity of finished sand, and the overall stable operation of the equipment. As the most frequently replaced key wear part, its working principle, fixing structure and material quality are critical to reducing plant downtime and operating costs.
MAG2100 Anvil Working Principle
The MAG2100 anvil is a stationary wear part mounted on the outer ring of the Mag’Impact 2100 VSI crushing chamber.
- Raw material feeds into the centre of the high-speed spinning rotor.
- Rotor impellers accelerate rock particles and eject them radially outwards at high velocity.
- The flying particles strike firmly against the fixed MAG2100 anvils. Intense impact force cracks and breaks the rock.
- Broken particles rebound and collide with each other for secondary crushing.
- Finished particles fall down through the clearance between rotor and anvil ring, then discharge from the bottom of the crusher.
The anvil acts as a rigid impact target. It absorbs high kinetic energy from incoming stones. The impact crushing mechanism produces cubical aggregate and manufactured sand with low flakiness index. MAG2100 anvils are made of high-chrome cast iron or ceramic composite material to resist heavy impact and abrasive wear.
Material Solutions for MAG2100 Anvil
Saikuang is a professional manufacturer of aftermarket VSI crusher wear parts, specializing in the production of fully compatible MAG2100 Anvil (QCA054). We offer three material options for the MAG2100 Anvil: High Chrome 26%, High Chrome 26% with Ceramic, and High Chrome 26% with Tungsten Carbide, matching different customer working conditions. All products undergo strict heat treatment, hardness testing, dimensional inspection and non‑destructive flaw detection to eliminate casting defects, ensure stable dynamic balance and excellent wear resistance, completely matching the working performance of original parts.
High Chrome 26%
This is the standard high‑chrome material with 26% chromium content. It has balanced wear resistance and impact toughness, fine and uniform internal metallographic structure, and strong resistance to particle scratching and abrasive wear. It is suitable for medium‑abrasive materials such as limestone, river pebble, recycled concrete and ordinary aggregate. It can meet the daily sand making and shaping needs of conventional crushing plants, with cost‑effective performance and stable service life.
High Chrome 26% with Ceramic
Based on the 26% high‑chrome matrix, this grade is reinforced with embedded ceramic particles. The combination perfectly merges the high toughness of the metal matrix with the ultra‑high wear resistance of ceramic. It is mainly used for crushing high‑hardness materials such as granite, basalt and quartz stone. Compared with standard high chrome 26%, the ceramic‑reinforced MAG2100 Anvil delivers significantly longer service life, reducing frequent replacement and production shutdown loss.
High Chrome 26% with Tungsten Carbide
This grade further enhances the 26% high‑chrome matrix with tungsten carbide reinforcement. Tungsten carbide provides extreme hardness and excellent anti‑abrasion performance, making it ideal for the most demanding high‑abrasion and high‑impact applications. It is particularly suitable for crushing hard rock, ore and other highly abrasive materials. The tungsten carbide reinforced MAG2100 Anvil offers the longest wear life among the three options, effectively minimizing downtime and maximizing productivity.
Advantages of Saikuang MAG2100 Anvil
Strict Standard Restoration: Fully compliant with MAG2100 original anvil parameters, precise positioning and firm fixing, no vibration during operation.
Diversified Material Options: Standard high chromium and high‑performance composite materials are available to adapt to various stone materials and working conditions.
Durable Performance: Excellent wear resistance and impact resistance, extending service life and reducing replacement costs.
Fast Supply & Customization: Spot supply of conventional models, support reverse engineering customization, flexible order quantity.
Professional Technical Support: Provide material selection suggestions, installation guidance and after‑sales technical services for the MAG2100 Anvil.
If you are looking for reliable aftermarket MAG2100 Anvil QCA054 for your Magotteaux Mag’Impact 2100 VSI crusher, welcome to contact Saikuang for free quotations and technical support.
